Pre-coated panels for waterproof, weather-resistant and anti-corrosion buildings

Mainstream coating types
High-weather-resistant polyester HDP coating: the first choice for cost-effectiveness, suitable for domestic factories and ordinary buildings
Fluorocarbon PVDF coating: high-end model for coastal, high UV, and chemical corrosive environments
Ordinary polyester PE coating: used for interior wall panels and suspended ceilings
Core Functions
Ultra-weather resistant and UV resistant, it will not fade or powder outdoors for a long time
Resistant to acid rain, salt spray, and chemical gas corrosion, waterproof and impermeable
Excellent flexibility, no cracking during bending and roller pressing
Self-cleaning, stain-resistant, and reduces later maintenance costs
Key performance parameters (JC/T 2607-2021 national standard)
1. Outdoor warranty period
High weather resistance polyester HDP: 8~15 years
Fluorocarbon PVDF: 15~25 years
Ordinary polyester PE: 5~8 years
2. Total coating thickness
High weather resistance polyester HDP: ≥25μm
Fluorocarbon PVDF: ≥23μm
Ordinary polyester PE: ≥20μm
3. 60° Luster
High weather-resistant polyester HDP: 5~10° matte
Fluorocarbon PVDF: 5~20° low light
Ordinary polyester PE: Customizable with any gloss
4. Divider adhesion
High weather resistance polyester HDP, fluorocarbon PVDF, and ordinary polyester PE: all are grade 0
5. Pencil hardness
High weather resistance polyester HDP: ≥HB
Fluorocarbon PVDF: ≥H
Ordinary polyester PE: ≥HB
6. Neutral salt spray
High weather resistance polyester HDP: ≥500h
Fluorocarbon PVDF: ≥800h
Ordinary polyester PE: ≥300h
7. QUV Accelerated Aging
High weather-resistant polyester HDP: 2000h, light retention ≥ 70%
Fluorocarbon PVDF: 3000h, light retention ≥ 80%
Ordinary polyester PE: 1500h, light retention rate ≥ 60%

Product Core Introduction
The soft pink pre-coated color steel plate adopts Morandi soft pink low saturation color to avoid the problem of bright pink being exaggerated and harsh. The zinc aluminum magnesium substrate is paired with a matte fluorocarbon/high weather-resistant polyester coating, with delicate and soft colors and a light luxury artistic texture. The surface of the board is matte frosted, without reflective pollution, suitable for personalized commercial, cultural and tourism buildings. The coating has strong color resistance, solving the industry pain point of pink that is prone to yellowing and fading, and supports customized special patterns and arc processing.

Adapt to usage scenarios (solve the pain points of scenario matching)
It focuses on internet celebrity homestays, cultural and creative district shops, women's themed commercial spaces, parent-child park supporting buildings, pink themed cultural and tourism check-in points, and boutique villa facades. Soft pink is highly recognizable and has a strong atmosphere. It is the core color of Internet celebrity commercial and check-in buildings. It can quickly enhance the attractiveness of buildings, adapt to personalized and youthful commercial projects, and create differentiated visual effects.

Core performance advantages (addressing long-term usage pain points)
Anti-powdering and yellowing: Pink's special weather-resistant color paste + fluorocarbon coating solution solves the problem of pink turning yellow and dirty outdoors for 1-2 years. After more than 5 years of outdoor use, the color remains soft and uniform;
Matte anti-reflective: The matte surface will not produce mirror reflections, avoiding the problem of bright light on the commercial street and improving pedestrian visual comfort;
Arc processing adaptation: The board has excellent ductility and can be used for arc roof and corner shapes, adapted to the personalized design of cultural and creative buildings, and meets the special-shaped structural needs of Internet celebrity check-in spots.

Purchase decision advice (precise selection reference)
Suitable for internet celebrity commercial, cultural and creative blocks, parent-child cultural tourism projects, and the first choice for pursuing architectural differentiation and check-in attributes; with sufficient budget and a weather resistance life of more than 10 years, directly choose the fluorocarbon coating version; if only used for interior decoration and short-term projects, the high-weather-resistant polyester version is more cost-effective, with a recommended thickness of 0.4-0.6mm, taking into account both shape and cost.

Common usage questions and answers
Q: Will pink steel plates turn yellow quickly outdoors?
A: The tendency of bright pink to turn yellow is a common industry problem. This Morandi soft powder is paired with a special weather-resistant color paste. The fluorocarbon model has a yellowing resistance life ≥10 years, polyester model≥ of 6 years, far exceeding that of ordinary pink sheets.
Q: Can I make a curved roof shape?
A: The board has excellent ductility, supports small radius arc bending and pressing, and can be adapted to the special-shaped roof and corner design of cultural and creative buildings to meet personalized modeling needs.
